This direct acting solenoid valve is designed for the interception of fluids compatible with its durable construction materials. With no minimum operational pressure required, it delivers reliable, long-lasting performance. Constructed from brass, stainless steel, and copper components, the valve features FKM seals and a brass orifice. Available in multiple sizes (L 5, 10, 15, 22, 27.5, 39.5), it comes with ISO 4400-compliant connectors and meets IEC 335 electrical standards, providing IP65 protection when fitted with a coil.
Solenoid valves
ODE Solenoid Valve 3/2 Way N.C. Direct Acting – Hose Connection Exhaust 1/8″
$103.20 +gst
Product Code: 31JN1XPV23; Standard: ISO 228/1; Gaskets: FKM (fluoroelastomer); Temperature Range: -10°C to +140°C; Medium: Mineral oils (2°E), gasoline, gas oil, fuel oils (5°E); Port Size: 1/8″; Ø Orifice: 2.3 mm; Kv Flow Rate: 2.3 l/min; Max Viscosity (cSt): 37; Max Viscosity (°E): ~5; Power (Watt): 5; Pressure (Min): 0 bar; Pressure M.O.P.D. (AC): 5 bar; Max Allowable Pressure (PS): 40 bar
Availability: 1 in stock
| Ways | 3/2 |
|---|---|
| Position | NC |
| Port Size | 1/8" |
| Standard | ISO 228/1 |
