Price range: $358.68 through $754.40 +gst
ATS Pneumatics single acting rotary actuators are spring return pneumatic actuators designed for reliable quarter-turn valve automation. Based on the Alpha Pompe RE Series, they feature a compact rack-and-pinion design with external travel adjustment for precise valve positioning and fail-safe return on air loss.
Manufactured with hard anodised extruded aluminium bodies, nickel-plated steel shafts, stainless steel fasteners, and ISO 5211 / NAMUR compatibility, these actuators are suitable for ball valves, butterfly valves, and industrial process automation applications.
| Thumbnail | SKU | Bore Size | Connection | Stock | Price | Quantity | |
|---|---|---|---|---|---|---|---|
| RE051SR | 51mm | F03/F05 | Availability: 2 in stock | $358.68 +gst | ||
| RE064SR | 64mm | F05/F07 | Out of stock | $411.89 +gst | ||
| RE076SR | 76mm | F05/F07 | Out of stock | $724.43 +gst | ||
| RE086SR | 86mm | F05/F07 | Availability: 1 in stock | $754.40 +gst |
Features:
| Bore Size | 51mm, 64mm, 76mm, 86mm |
|---|---|
| Connection | F03/F05, F05/F07, F05/F07, F05/F07 |
Reviews
There are no reviews yet.
